modular Conveyor cleated belt

Name: modular Conveyor cleated belt
Brand: SSKP Industries
Price: 575000.0 INR
Availability: InStock

Price 575000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

modular Conveyor cleated belt Specification

Belt Type
Cleated Modular Plastic, with interchangeable sections

Power Source
Electric motor

Surface Finish
Smooth/Antislip as per requirement

Features
High durability, modular design, easy maintenance, corrosion resistant, customizable cleat height

Thickness
4 mm to 20 mm (customizable)

Material
High-Density Polyethylene (HDPE), Polypropylene (PP), or Acetal

Type
Modular Cleated Belt Conveyor

Structure
Modular Frame, Stainless Steel or Powder-Coated Mild Steel

Belt Conveyor
Available with cleats

Vertical Conveyor
Yes

Pneumatic Conveyor
No

Resistant Feature
Oil, Water, Chemical, and Wear Resistant

Load Capacity
Customizable up to 2000 kg/m

Voltage
220-440V (For powered modules)

Power
0.75 kW to 3 kW depending on drive motor

Speed
0.1-2.5 m/s (adjustable)

Usage & Applications
Bulk material handling, inclined elevation, packaging, food, pharma, automotive, recycling

Number of Cleats per Meter
Customizable as per product and application

Belt Width Range
100mm to 1200mm

Maintenance
Low, easy to clean and replace modules

Edge Design
Sealed or open edge for easy sanitation

Color Options
Blue (food grade), white, custom on request

Drive Method
Direct drive/geared motor

Section Length
Modular segments from 500mm up

Cleat Height Options
Standard 25mm, 50mm, 75mm (custom available)

Operating Temperature
-10C to +80C

Noise Level
< 65 dB

Maximum Incline Angle
Up to 45 (depending on load and cleat height)

Frame Material
Anodized/aluminum profile or SS304

Installation
On-site support available

Accessories
Side guides, hoppers, chutes, collection bins

modular Conveyor cleated belt Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

About modular Conveyor cleated belt

NEWLY UPDATED CASHEW PEELING MACHINE

Cashew kernel pneumatic peeling Machine Model SSKP-PMS 300. Nominal capacity 300 kg per hour Three Head Cashew Peeeling Machine with 6 SIZER CASHEW PIECES SEPARATOR. Cashew pieces separate peeled kernel into sizes BB,SWP,LWP,JK, Splits and Wholes. And Stand .Material of Construction for kernel contact parts SS 304 grade, 3.5 gauge . Air Nozzles made of Brass. Peeling machine. Supplied with electrical control panel. All Accessories of Peeling Machine spares would be high Quality Janatics spares.

Installation spares would be free of cost

1) 1/2 inch Filter Regulator Combination :- 4Q

2) Pressure Gauge :- 4 qty.

3) Regulator Clamp :- 4 qty.

4) 12 mm PU TUBE :- 10.

5) 8mm PU TUBE :- 10.

6) Air Gun and it's Connector :- 1.

7) 1/2 inch PU Connectors :- 8 Nos.

Flexible Modular Design

The conveyor's modular structure allows easy customization, accommodating various cleat and sideguard heights to meet your specific material handling requirements. Its interlocking sections provide quick assembly, expansion, or replacement, ensuring minimal downtime and scalable solutions as your operations grow.

Adaptable for Challenging Environments

Designed for demanding industrial settings, this belt conveyor withstands temperature extremes from -20C up to 80C. The robust materials-HDPE, PP, or Acetal-and corrosion-resistant structure make it an excellent fit for food, pharmaceutical, automotive, and recycling applications.

Effortless Maintenance & Hygiene

Cleaning is simplified thanks to the washdown-compatible design and smooth or antislip belt finishes, which support stringent hygiene standards, particularly critical in food and pharma sectors. The integrated self-tensioning system also means less manual adjustment and reduced maintenance needs.

FAQ's of modular Conveyor cleated belt:

Q: How can I select the appropriate cleat height for my application?

A: The ideal cleat height depends on the type and volume of materials being conveyed, as well as your incline requirements. Standard options include 20 mm, 50 mm, and 75 mm, with custom heights available on request. Please consult our technical team to determine the optimal configuration for your process.

Q: What makes this modular cleated belt conveyor suitable for food or pharmaceutical use?

A: This conveyor is crafted from FDA-approved materials, such as food-grade HDPE, PP, or Acetal. Its design ensures washdown compatibility for easy cleaning, and smooth or antislip belt options meet stringent hygiene requirements. Additionally, the system complies with CE and ISO safety standards.

Q: Where can this conveyor system be installed and used?

A: The modular cleated belt conveyor is versatile for installation in various industrial settings-such as floor-mounted setups or mobile configurations with wheels. It is widely used in food processing, packaging, pharmaceuticals, automotive, recycling, and bulk material handling.

Q: What is the recommended cleaning process for this conveyor?

A: Routine cleaning involves washdown with water or approved detergents, facilitated by the conveyor's washdown-compatible design. The smooth or antislip surface options further aid quick and thorough cleaning, ensuring optimal sanitation.

Q: What are the benefits of the integrated self-tensioning mechanism?

A: The integrated self-tensioning system automatically maintains correct belt tension, reducing the need for manual adjustments. This improves belt lifespan, minimizes maintenance downtime, and ensures consistent performance.

Q: How customizable is the conveyor in terms of structure and size?

A: Nearly every aspect is customizable: cleat and sideguard heights, belt thickness (4 mm-20 mm), frame material (stainless steel or powder-coated mild steel), power source, voltage, and speed settings. The modular design allows for tailored solutions to match your processes.
